Concrete Twin Shaft Mixer Price
2022.03.30
The JS series concrete twin shaft mixer price is basically it depends on the model, and it is also influenced by detailed configuration. The reasonable blade arrangement of the material movement trajectory of the twin shaft concrete mixer can not only improve the hardness of the concrete and the productivity of the concrete. So the concrete twin shaft mixer models are welcomed on the market!
The main transmission mechanism of concrete twin shaft mixer is mainly composed of small pulley, large pulley, synchronous shaft, belt, stirring reducer, motor and connecting body and other parts. The concrete mixer reducer is made of excellent materials, fine manufacturing, stable operation, low noise, large bearing capacity, high impact resistance and long service life. The installation form of the stirring reducer is flange type, which is convenient and reliable to install. The structure of concrete twin shaft mixer is compact, the volume is small, and the shape is beautiful. The output adopts the involute spline link mode to output to the stirring spindle. The unloading device consists of a turntable, an arc-shaped door, a cylinder, a sealing rubber ring, and a strip. The arc-shaped door is fixed on the bottom of the mixing drum through the bearing seat. The linear motion of the cylinder is converted into the rotary motion of the arc-shaped door to complete the opening and closing of the discharge door; the anti-leakage effect of concrete materials is mainly through adjusting the gap, which is generally adjusted before leaving the factory and can be used directly by the user.
The electrical system control circuit of the concrete twin shaft mixer price is equipped with circuit breakers and thermal relays, which have the functions of short-circuit protection and overload protection. All control buttons and indicator lights are arranged on the operation box door, and are equipped with door locks, and there are protective small doors outside the buttons. The electrical components in the distribution box are installed on the electrical installation board, which is safe, reliable, and easy to operate and maintain. The total electrical power supply is a three-phase five-wire system (or three-phase four-wire system) power supply, and the voltage tolerance is ±10%, otherwise it is prohibited to use. The control power supply is 220V. The surface temperature rise of the electric motor is charged with 0.5MW insulation to the shell.
