Self Loading Concrete Mixer 6.5 Cubic

  •

    Production Capacity: 6.5 Cubic Meter/Drum

  •

    Rated Power: 92 kw

  •

    Fuel Tank: 370 L

  •

    Water Tank: 1465 L

Share with:
  • Product Details
  • Configuration and Drawing
  • Technical Features
  • Inquiry
Self-loading concrete mixer 6.5 cubic meter makes full use of the function of concrete transit mixer and mixing plant, which realizes the automatic loading, metering, mixing and discharging of concrete. Self loading transit mixer can realize the transportation of concrete at construction sites, it greatly improves the working efficiency and reduces the production time and cost. With the continuous demand of construction market, self loading concrete transit mixer will gradually show its importance and advantages.

Components of self loading concrete transit mixer truck


Self loading concrete transit mixer consists of a cab, a chassis, a drive system, a hydraulic system, an unloading lifting cylinder, a speed reducer, a mixing tank, a rotating frame, a rotating disk, a hopper, and a shovel. Self loading concrete mixers have compact structure and it mainly consists of 5 parts:

1. Under the mixer is chassis, which is to support the mixer. Its powerful engine offers power and ensures that the machine can function on and on;

2. Mixing drum is driven by the powerful engine and achieves rapid mixing, mixing quality is high, in addition self loader mixer, SICOMA twin shaft concrete mixer also has advantages of large output and good uniformity;

3. Hydraulic system is the core of discharging materials, this kind of discharging method has been put into wide use, and its discharging speed is pretty fast,which can effectively save the construction cost;

4. Independent water supply system can offer the water continuously and ensure the normal function of the machine;

5. The space of the operating room is small, but can achieve perfect working process. It has attractive appearance and compact structure, all the compositions co-operate fully with each other and run efficiently.

self loading transit mixer suppliers

Advantages of Haomei Self Loading Concrete Mixer 6.5 Cubic Meter


1. Self loading concrete mixture for sale can rotate 270 degrees;
2.Self load, meter, mix and discharge;
3.Compact structure and easy movement—four wheels steering;
4. High working efficiency and less energy consumption;
5. High stirring quality and short stirring time.
6. The main hydraulic components are imported!
7. At least 5 workloads are saved per day!
8. Save electricity 100 degrees everyday without a blender!

Haomei Service Promise:


1. One year warranty;
2. Go to your site and help you installation and debug;
3. Free training for your operator;
4. Any problem, we will be here to serve you, or go to your city, check and maintain;
5. Spare parts are in stock, any needs, please leave your message on my website, we will arrange shipment within 48 hours;
6. Introduce other users to buy our self loading concrete mixers, we will give you some commission.


Equipment Model

6.5 cubic Self Loading Transit Mixer

Production Capacity

6.5 Cubic Meter/Drum

Engine Model

Weichai deutz 6105 Turbo-Charged

Rated Power

92kw//125ps

Gear Box Model

ZL-315 Power Shift Gearbox

Gear

2 Forward 2 Back

Fuel Tank

370L

Fuel consumption L / h

13.25L

Total Hydraulic System Capacity

278 Liters

Oil Tank

16 Liters

Reducer

KY07-5-J

Hydraulic Pump

Inter pump

Hydraulic Motor

SUNNY63

Water Tank

1465L

Water Supply

Time Relay

Overall Dimensions(L*W*H)

8450*3050*4830

Total Weight

12520kg

Drum Capacity

9000L

Drum rotation speed

16.5 rpm

Wheel base

2,850 mm

Max. speed

40 km/h

Max. climbing degree

45°

Min. turning radius

4,800 mm

Min. ground clearance

350 mm

Left and right track

2100mm

Sand feeding time (minutes / tank)

12

self loading transit mixer for sale

1. Shot blasting machine


When the elements are moved in to the machine, thousands of the little steel balls will heat on the surface of elements. Then the surface will become uneven, and it will increase the adhesive force. So it will ensure good painting.


ajax fiori argo 4000


2. Robot welding


Here are advanced technology of welding robots, which ensures high working efficiency and high accuracy


ajax fiori argo 4000 price


3. Closed painting room


In order to assure good painting and environmental protection, here is closed painting room. The machine will be shinning even after long time use. Moreover, we can also meet the environmental standards, so that we can manufacturer and delivery the equipment for our customers on time.


ajax fiori concrete mixer


4. Sufficient elements stored


Here are sufficient elements stored in our factory, which ensures short delivery time. Meanwhile, we have ability to accept big orders from our customers.


ajax self loading concrete mixer price


5. Strict quality inspection


Here are quality inspection department, and strict inspection guarantees that the unqualitified equipment will be reworked and will not be delivered to our customers.


ajax fiori 2000 price


6. Test run


Here are wide areas for our customers to test the self loading concrete mixer truck, and welcome to test the mixer truck in our factory. Driving, feeding, mixing, discharging and climbing are available.


schwing stetter slm 4000
